IEI Integration ICECARE 7 User Manual
Icecare-07, User manual, Model
ICECARE-07 Mobile Field Assistant
Page i
User Manual
7” Mobile Field Assistant with TI Sitara™ AM3715 CPU,
Touchscreen, Android 4.1.2 OS, HSUPA/GPRS/GSM, Bluetooth,
Wi-Fi, GPS, RFID Reader, 1D/2D Barcode Scanner,
2-megapixel and 5-megapixel Cameras, RoHS Compliant
Rev. 1.12 – 10 April, 2014
MODEL:
ICECARE-07
Table of contents
Document Outline
- 1 Introduction
- 2 Unpacking
- 3 Installation
- 3.1 Anti-static Precautions
- 3.2 Installation Precautions
- 3.3 Battery Pack Installation
- 3.4 SIM Card Installation (Optional)
- 3.5 SD Card Installation
- 3.6 Carrying Strap Kit Installation
- 3.7 Mounting the ICECARE-07 (Optional)
- 3.8 I/O Connectors
- 3.9 Using the Docking Cradle (Optional)
- 3.10 Using the Metal Stand
- 4 Using the ICECARE-07
- 5 System Maintenance
- 6 Interface Connectors
- 6.1 Peripheral Interface Connectors
- 6.2 Internal Peripheral Connectors
- 6.2.1 Barcode Scanner Connector (JP2)
- 6.2.2 Battery Connectors (JP4, JP5)
- 6.2.3 Camera CPLD Programmable Connector (JP1)
- 6.2.4 Debug Message Connector (CON1)
- 6.2.5 Digital Microphone Connector (MIC1)
- 6.2.6 Flashlight Connector (CN5)
- 6.2.7 Front Camera Connector (X2)
- 6.2.8 Panel Connector (LCD3)
- 6.2.9 Rear Camera Connector (CN6)
- 6.2.10 RFID Antenna Connector (CN7)
- 6.2.11 SIM Card Connector (SC1)
- 6.2.12 Speaker Connector (CN3)
- 6.2.13 Touchscreen Connector (CN16)
- 6.3 External Interface Panel Connectors
- A Safety Precautions
- B Hazardous Materials Disclosure
