ECW-281B-R21/N270 Embedded System
Page 22
Figure 3-3: ATX Power Supply Enable Connector Location
PIN NO. DESCRIPTION
1 +5V Standby
2 GND
3 PS-ON
Table 3-3: ATX Power Supply Enable Connector Pinouts
3.3.3 Audio Connector (10-pin)
CN Label: AUDIO1
CN Type: 10-pin header
CN Location: See
703H703H705H
Figure 3-4
CN Pinouts: See
704H704H706H
Table 3-4
The 10-pin audio connector is interfaced to an audio line-out connector and provides
output of audio signals from the system.
Figure 3-4: Audio Connector Pinouts (10-pin)
