ICP-P4/PM/CM Appendix-E
AGP-R7000
Appendix E
Table E1.20 J4 Pinout - Contd.
Pin No.
Signal
Pin No.
Signal
61
GND
62
AD22
63
AD19
64
AD20
65
AD17
66
GND
67
C/BE2#
68
AD18
69
VDDQ1.5
70
AD16
71
IRDY#
72
FRAME#
73
DEVSEL#
74
VDDQ1.5
75
-
76
TRDY#
77
GND
78
STOP#
79
PERR#
80
PME#
81
SERR#
82
GND
83
C/BE1#
84
PAR
85
VDDQ1.5
86
AD15
87
AD14
88
AD13
89
AD12
90
VDDQ1.5
91
AD10
92
AD11
93
GND
94
AD9
95
AD8
96
C/BE0#
97
AD_STB0
98
GND
99
AD7
100
AD_STB0#
101
VDDQ1.5
102
AD6
103
AD5
104
AD4
105
AD3
106
VDDQ1.5
107
AD1
108
AD2
109
GND
110
AD0
111
VREFCG
112
VREFGC
113
VGA_R
114
GND
115
VGA_G
116
HSYNC
117
GND
118
VSYNC
119
VGA_B
120
VB_EN
