©2004 Inova Computers GmbH Page 2-9 Doc. PD00941013.001
ICP-CM Configuration
CompactPCI
®
2
2.6 Inova CM PCI Device List
Table 2.60 shows the available PCI devices both on-board and off-board (CompactPCI backplane).
It should be noted that the interrupt routing assumes a standard Inova backplane configuration
with a right-hand system slot.
Table 2.60 Legacy I/O Map (ISA Compatible)
1) CompactPCI backplane numeration is based on a 7-slot backplane and refers to the logical (and
not physical) slot number
Bus
No.
Device
Number
Function
Number
IRQ
Device /
Vendor ID
0 0x00 0x00 N/A 0651 1039
0 0x01 0x00 N/A 0001 1039
0 0x02 0x00 N/A 0008 1039
0 0x03 0x00 N/A 7001 1039
0 0x03 0x01 N/A 7001 1039
0 0x03 0x02 N/A 7001 1039
0 0x03 0x03 N/A 7002 1039
0 0x02 0x05 N/A 5518 1039
0 0x02 0x07 N/A 7012 1039
0 0x04 0x00 N/A 0900 1039 SiS962 LAN
0 0x08 0x00 INTA# 0020 3388
0 0x09 0x00 INTB# 1229 8086
1 0x00 0x00 INTA# 6325 1039
2 0x09 INTB#
2 0x0A INTC#
2 0x0B INTD#
2 0x0C INTA#
2 0x0D INTB#
2 0x0E INTC# CompactPCI Slot 3
2 0x0F INTD#
Bus No. 0 = On board; Bus No. 1 = AGP; Bus No. 2 = CompactPCI Bus
CompactPCI Slot 2 [next to Master]
SiS962 B/S Audio
CompactPCI Slot 4
CompactPCI Slot 8
1)
AGP
LAN 82551 (Fast Ethernet)
PCI-PCI Bridge
CompactPCI Slot 6
CompactPCI Slot 5
CompactPCI Slot 7
Description
SiS651 Host Bridge
SiS651 Virtual PPB
SiS962 LPC
SiS962 USB0 OHCI
SiS962 USB1 OHCI
SiS962 IDE
SiS962 USB2 OHCI
SiS962 USB0 EHCI
