©2004 Inova Computers GmbH Page C-5 ICP-P4/PM/CM Appendix-C
Appendix C ITM-RIO
CompactPCI
®
C
Table C1.3 ITM-RIO-D-x Connector Description
Note:
When setting up the rear I/O (D) the
following should be observed:
Either the LPT interface or the COM ports
or the floppy disk interface can be used
(not combined)
Only the required device should be
attached. Installing or attaching hard-
ware that is not required will prevent the
actual device from being configured.
Example: if a FD is physically attached
but the COM ports are required, then
these ports will not work even if they are
correctly configured in BIOS!
Connector Description
J1 CompactPCI rear I/O connector
J2 Standard 3.5" IDE header
J3 Standard slim-line floppy disk interface
J4 Beeper (loudspeaker)
J5 Reset
Open: COM2 is configured for RS232 communication
Closed: COM2 is configured for RS485 communication
Open: COM1 is configured for RS232 communication
Closed: COM1 is configured for RS485 communication
J9 LPT1
J10 COM2
J11 VGA physical interface
J12 COM1
J13 USB physical interface (USB 4)
J14 Fast Ethernet physical interface
J15 PS-2 mouse & keyboard interface [only keyboard on ITM-RIO-D-2 ]
J7
J8
