©2004 Inova Computers GmbH
Page 1-20
Doc. PD00941013.001
Product Overview
ICP-CM
1.50 Power Consumption
The illustration provided in figure 1.50 is for reference only and serves to show the ‘typical-maxi-
mum’ power consumption of the ICP-CM CPU. Variations in ‘processor manufacture and onboard
silicon make accurate testing impossible and hence, the figures shown in this illustration are sub-
ject to fluctuation.
Note:
There is no such thing as a typical
application and so, the CPU power
consumption was measured with the
‘processor in idle state, in BIOS mode
(i.e. the OS power management
features were not being utilised) and
software stressed to 100%
To stress this CPU, the following software was installed:
Ī
Microsoft Windows XP SP1,
Ī
DirectX 9.0b,
Ī
ATI Catalyst 3.9 video driver
on a 20GByte HD mounted on the baseboard (8HP with HD carrier) with 256Mbyte PC2100
memory and including the Radeon R7000 AGP piggyback with 32MByte video memory.
Figure 1.50 ICP-CM Power Consumption
