©2004 Inova Computers GmbH
Page 2-8
Doc. PD00941013.001
Configuration
ICP-CM
2.5 Inova CM SMB Devices
Table 2.50 shows the addressing of the SMB (System Management Bus) Devices
Table 2.50 SMB Devices
Address b[7:1]
0101 100
1010 000
1010 101
1010 110
1010 111
1101 001
Device
LM87 (Temperature Monitor)
EEPROM SPD DDR Bank 0
EEPROM TOP EXTENSION (e.g. ICP-HD-3) ID
EEPROM RIO PANEL ID
EEPROM Vital Product Data / General Purpose
ICS952001 (Timing Hub)
