©2004 Inova Computers GmbH
Page 1-15
Doc. PD00941013.001
ICP-CM
Product Overview
CompactPCI
®
1
1.45 Interface Positions
Figure 1.45 Interfaces
Figure 1.45 shows the typical positioning of the front panel extension modules for mouse, key-
board, COM1, COM2, and LPT interfaces.
Note
A hard disk, if installed, will generally
be fitted to the piggyback containing
the combined PS-2 mouse / keyboard,
USB2.0, COM1 and COM2 interfaces.
