Page C-11

ICP-P4/PM/CM Appendix-C

Appendix C

ITM-RIO

CompactPCI

C1.9 USB Interface (USB 4)

Standard to all rear I/O (D) transition modules is the peripheral USB (1.1) port. Figure C1.9 and
Table C1.9 provide the pinout and signal description of this standard Ethernet interface respec-
tively.

Figure C1.9 USB Interface Pinout

Table C1.9 USB Connector Signals

Pin No.

Signal

+5V

USB P2-

USB P2+

GND
