Appendix E AGP-R7000
CompactPCI
®
E
E1.1 Specifications
Interface AGP 4x (120-pin connector)
Video ATI Radeon with 32MByte RAM
Controller
Screen Options Resolution Colour Depth Refresh
(TFT & VGA) 1920 x 1200 32-bit 72Hz
1920 x 1200 16-bit 80Hz
2048 x 1536 16-bit 60Hz
TMDS 1600 x 1200 24-bit 60Hz
Configuration DIP switch for DDC data or fixed resolution
User Interfaces 15-pin D-Sub for front-panel VGA or
15-pin D-Sub for front-panel TMDS (PanelLink)
2x27 pin ZIF connector for TFT (GigaST
Ȣ R)
Options Front or rear-panel VGA 1)
Front-panel TMDS and rear-panel VGA 2)
Software Windows ® 2000 ® , Windows ® XP ®
Support
Power Req. +3.3V (2W), +5V (2W) (typically)
Mass 40g (typically)
Oper. Temp. 0
°
C to +60
°
C
Storage Temp. -40
°
C to +85
°
C
Humidity 5% to 95% (non-condensing) @ 40
°
C
Warranty Three-year limited warranty
1) Two VGA monitors can be connected simultaneously with identical video information on both - the Radeon
graphics engine must be configured accordingly. An alternative is also available where the content appearing
on the 2nd display is different to that of the first. The disadvantage of this configuration is that if a monitor is
not connected to the front-panel (CRT1) the video content cannot be displayed on CRT2 (rear) until the OS has
been initialised and the video driver initialised. If a BIOS upgrade is required or the settings need to be altered
etc. then, without the CRT on the front-panel, the user will not see anything which makes the task almost
imposible!
2) This is the only supported mode whereby (independent) video can be produced via the front DVI-D and a rear
connected analog (CRT) device.
Both options support TFT - video content can be selected to be the TMDS or CRT
