Table e1.20 j4 pinout, Compactpci, Agp-r7000 – Inova PD00941013.001 User Manual
Page 97: Appendix e
©2004 Inova Computers GmbH
Page E-5
ICP-P4/PM/CM Appendix-E
Appendix E
AGP-R7000
CompactPCI
®
E
Table E1.20 J4 Pinout
Pin No.
Signal
Pin No.
Signal
1
USB6+
2
GND
3
PC_BEEP
4
USB6-
5
VCC3.3
6
AC_RESET#
7
SYNC
8
BITCLK
9
SDATA_OUT
10
VCC5
11
INTB#
12
SDATA_IN
13
GND
14
INTA#
15
CLK
16
RST#
17
REQ#
18
GND
19
ST0
20
GNT#
21
VCC3.3
22
ST1
23
ST2
24
-
25
RBF#
26
VCC3.3
27
-
28
PIPE#
29
GND
30
WBF#
31
SBA0
32
SBA1
33
SBA2
34
GND
35
SB_STB
36
SBA3
37
VCC3.3
38
SB_STB#
39
SBA4
40
SBA5
41
SBA6
42
VCC3.3
43
AD31
44
SBA7
45
GND
46
AD30
47
AD29
48
AD28
49
AD27
50
GND
51
AD25
52
AD26
53
VDDQ1.5
54
AD24
55
AD_STB1
56
AD_STB1#
57
AD23
58
VDDQ1.5
59
AD21
60
C/BE3#
