HP Compaq nx5000 series - Manual (Page 45)

1–40 Maintenance and Service Guide
Product Description
5 S-Video connector Connects an optional S-Video device, such
as a television, VCR, camcorder, overhead
projector, or video capture card.
6 External monitor
connector Connects an optional external monitor
or overhead projector.
7 1394 connector Connects an optional IEEE-1394 compliant
device to the notebook.
8 RJ-45 (network) jack Connects a network cable.
9 USB connectors (2) Connect optional USB 1.1- and
2.0-compliant devices to the notebook,
using a standard USB cable.
10 Headphone jack Produces system sound when connected
to optional powered stereo speakers,
headphones, headset, or television audio.
11 Microphone jack Connects an optional monaural microphone.
12 Hard drive bay Holds the primary hard drive.
13 MultiBay device slot Holds a MultiBay device.
Table 1-5
Rear and Left-Side Components (Continued)
Item Component Function
