6–2 Maintenance and Service Guide
Specifications
Stand-alone power requirements
Nominal operating
voltage
Peak operating power
14.4 V dc (8-cell battery)
10.8 V dc (6-cell battery)
65 W
Temperature
Operating (not writing
optical)
Operating (writing
optical)
Nonoperating
0°C to 35°C
5°C to 35°C
-20°C to 60°C
32°F to 95°F
41°F to 95°F
-4°F to 140°F
Relative humidity (noncondensing)
Operating
Nonoperating 10% to 90%
5% to 95%, 38.7°C (101.6°F)
maximum wet bulb temperature
Altitude (unpressurized)
Operating (14.7 psia to
10.1 psia)
Nonoperating (14.7
psia to 4.4 psia)
-15 m to 3,048 m
-15 m to 12,192 m
-50 ft to 10,000 ft
-50 ft to 40,000 ft
Shock
Operating
Nonoperating 50 g, 2 ms, half-sine
175 g, 2 ms, half-sine
Random vibrations
Operating
Non-operating 0.75 g
1.50 g
✎
Applicable product safety standards specify thermal limits for
plastic surfaces. The notebook operates well within this range of
temperatures.
Table 6-1
Notebook (Continued)
