Removal and Replacement Procedures
Maintenance and Service Guide 5–3
5.2 Disassembly Sequence Chart
Use the chart below to determine the section number to be
referenced when removing notebook components.
Disassembly Sequence Chart
Section Description # of Screws Removed
5.3 Preparing the Notebook for Disassembly
Battery pack
Hard drive 0
2 to remove,
6 to disassemble
5.4 Notebook Feet 0
Section Description
# of Screws
Removed
5.5 Mini PCI Communications Board 1 captive screw
WARNING: To prevent an unresponsive system
and the display of a warning
message, install only a Mini PCI
device authorized for use in your
notebook by the governmental agency
that regulates wireless devices in your
country. If you install a device and
then receive a warning message,
remove the device to restore
notebook funtionality. Then contact
Customer Care. 0
5.7 Bluetooth Wireless Communications
Board 2
1 captive screw
5.8 Keyboard 2
5.9 Switch Cover 2
5.10 Modem Board 2
5.11 Memory Module 0
5.12 Keyboard Plate 0
