20 led board, 20 led board –48, 20led board – HP Compaq nx5000 series User Manual
Page 156
5–48
Maintenance and Service Guide
Removal and Replacement Procedures
5.20LED Board
1. Prepare the notebook for disassembly (
Section 5.3
) and
remove the following components:
❏
Keyboard (
Section 5.8
)
❏
Memory shield (
Section 5.10
)
❏
Switch cover (
Section 5.11
)
❏
Keyboard plate (
Section 5.12
)
❏
Display assembly (
Section 5.16
)
❏
Top cover (
Section 5.17
)
❏
Speaker assembly (
Section 5.19
)
2. Turn the notebook right-side up, with the front toward you.
Spare Part Number Information
LED board (includes cable)
353391-001
