Page 83
4-3
Connecting Cables
Introduction
Introduction
This chapter discusses connecting cables to one of the following ports on
your Model 744 Board Computer from a peripheral or accessory:
•
Text terminal (RS-232) connection
•
An audio connection
•
A video (graphics circuit) connection
•
A keyboard or mouse (PS/2 ports) connection
•
A Network (AUI LAN) connection
•
Printer (HP parallel and RS-232) connections
•
A SCSI port connection
Figure 4-1 shows the front panel connectors for the Model 744.
Figure 4-1
Model 744 Front Panel Connectors
Kbd
PS/2
PS/2
0
1
SE SCSI
