Hp installation (other than primary cpu) – HP 744 User Manual
Page 77
3-11
Typical Installation in a VME Card Cage
HP Installation (Other Than Primary CPU)
HP Installation (Other Than Primary CPU)
The Model 744 Board Computer’s P2 connector has a local bus on user-
defined pins. The VME slot used by the Model 744 must make no connec-
tions to J2/P2, rows A and C.
Refer to IEEE STD 1014-1987, Chapter 7, for more information on user-
defined pins used in VME backplane connectors.
