Page 113
6-3
Solving Problems
Interpreting the LEDs
Interpreting the LEDs
The Model 744 provides two LEDs, located to the left and right of the reset
switch, as shown in Figure 6-1. The red LED is labeled SYSFAIL and the
green LED is labeled POWER.
Figure 6-1
Model 744 LED Location
Red LED
Reset Switch
Green LED
