HP AMD Geode ECM-5510 User Manual
Page 35
User’s Manual
ECM-5510 User’s Manual
35
2.4.12.2 Signal
Configuration – TFT Panel Display (CN3)
Signal
18-bit TFT
24-bit TFT
P0
-
B0
P1 -
B1
P2
B0
B2
P3 B1
B3
P4
B2
B4
P5 B3
B5
P6
B4
B6
P7 B5
B7
P8
-
G0
P9 -
G1
P10
G0
G2
P11 G1
G3
P12
G2
G4
P13 G3
G5
P14
G4
G6
P15 G5
G7
P16
-
R0
P17 -
R1
P18
R0
R2
P19 R1
R3
P20
R2
R4
P21 R3
R5
P22
R4
R6
P23 R5
R7
