User’s Manual

ECM-5510 User’s Manual

13

1.5 System Specifications

System

CPU

Onboard AMD Geode GX466 333 MHz

Note: Available in different CPU speeds by request

BIOS

Award 512 KB Flash BIOS

System Chipset

AMD Geode GX466/CS5535

I/O Chip

Winbond W83627HF-AW

System Memory

64/128/256 MB DDR SDRAM onboard

One 184-pin DIMM socket supports up to 512 MB DDR 200/266 SDRAM

SSD

One M-Systems DiskOnChip, one CompactFlash Type I/II socket

Watchdog Timer

Reset: 1 sec.~255 min. and 1 sec. or 1 min./step

Expansion

One PC/104 connector, one PCI slot (PCI Rev. 2.2 compliant)

I/O

MIO

2 x EIDE (Ultra DMA 66), 1 x FDD, 1 x LPT, 3 x RS-232,

1 x RS-232/422/482, 1 x K/B, 1 x Mouse

IrDA

115k bps, IrDA 1.0 compliant

USB

4 x USB 1.1 ports

DIO

16-bit General Purpose I/O for DI and DO

Display

Chipset

AMD Geode GX466 with integrated 2D graphics engine

Display Memory

8/16 MB frame buffer using system memory

Resolution

CRT mode: 1280 x 1024 @ 24 bpp (60 Hz)

LCD mode: 1280 x 1024 @ 24 bpp (85 Hz)

VGA/LCD Interface

PCI bus VGA/LCD interface

Supports 18/24-bit TFT panels

LVDS

Single channel 24-bit LVDS

Audio

Chipset

AMD Geode CS5535

AC97 Codec

VIA VT1612A

Audio Interface

Mic in, Line in, CD Audio in, Line out

Ethernet

LAN 1

Realtek RTL8100C

Optional Intel® 82551QM/82551ER

Ethernet Interface

100Base-Tx Fast Ethernet compatible
