ECM-5510

30 ECM-5510 User’s Manual

2.4.5

COM2/4/3/1 Pin 9 Select (JP7, JP8, JP9, JP10)

* Default

+12V

+5V

Ring*

2.4.6

LCD Inverter Power Select (JP11)

* Default

+12V*

+5V

JP7

JP8

JP9

JP10
