4 Ports 11g Wireless ADSL2/2+ Router 110
4.4.13.1 Dynamic Routing Configuration Procedure
1. Check Enable RIP.
2. Select the RIP Protocol RIP v2 for training purpose. The Enable Password field is enabled.
Note—The same RIP protocol should be used to enable dynamic routing on all routers on the network.
3. Check Enable Password and enter a password. This is an optional field for additional security.
4. For LAN group 1 and LAN Group 2, leave “Both” checked in the Direction field.
5. Click Apply to temporarily save the settings.
6. Click Apply again when you finish making all the changes.
7. To make the change permanent, click on Save All.
