Hitachi Ultrastar 15K450 (FC-AL) Hard Disk Drive Specification
266
• Address to Translate contains the address to translate. If the logical block format is specified, the first four bytes of
the field (bytes 6 to 9) contain the LBA and the remainder must be zero. For the physical format the address must be
specified as follows.
Table 226: Address to translate
Byte
Bit
7 6 5 4 3 2 1 0
6-8 Cylinder Number
9 Head Number
10-13 Sector Number or Bytes from Index
