Hitachi Ultrastar 15K450 (FC-AL) Hard Disk Drive Specification
245
19.27.4 Receive Diagnostic Page A0h
The Receive Diagnostic Device LED Control Page A0h is returned as a result of the Send Diagnostic Device LED Control
Page A0h. For a description of the parameters in this page, see 19.34.3, "Send Diagnostic Page A0h" on page 231.
Table 208: Device LED Control Page - Receive Diagnostic
Byte
Bit
7
6
5
4
3
2
1
0
0
Page Code = A0h
1
Reserved = 0
2
3
(MSB) Page Length = 0002h
(LSB)
4
Reserved = 0
5
Reserved = 0
SBDL
