Hitachi Ultrastar 15K450 (FC-AL) Hard Disk Drive Specification
134
• Protocol Identifier is valid only when PIV=1. Protocol Identifier = 0 indicates Fibre Channel devices. Protocol Identi-
fier = 6 indicates SAS devices
• Code Set specifies the data type for the identifier field. Code Set = 1 indicates binary data
• PIV (Protocol Identifier Valid) set to one indicates that the Protocol Identifier field contains a valid value.
• Association specifies the entity with which the Identifier field is associated: 1h for Target or Relative Port.
• Identifier Type specifies the format and assignment authority for the identifier: 3h indicates NAA format of the WWID
for Target Port.
• Identifier fields contain the actual Identifier Descriptor.
- The Target Port Identifiers are defined in the NAA IEE WWID format where:
World Wide ID is a World Wide ID is a 64-bit unique identification for each drive. The format is: 5000CCAh
xxxh yyb n wherexxx is the 12-bit block assignment defined for each model and manufacturing site yy is the 2-bit
port/node ID select n is the 22-bit drive unique serial number.
8-9 Reserved = 0
10-11 Initiator Port Transport ID Length = 0
12-13 Reserved = 0
14-15 Primary Target Port Descriptors Length = 0Ch
16 Protocol Identifier Code Set = 1
17 PIV=1 RSVD Association = 1 Identifier Type = 3
18 Reserved = 0
19 Identifier Length = 8
20-27
(MSB)
Primary Target Port Identifier (World Wide ID)
(LSB)
28-29 Reserved = 0
30-31 Secondary Relative Port = 0002h
32-33 Reserved = 0
34-35 Initiator Port Transport ID Length = 0
36-37 Reserved = 0
38-39 Secondary Target Port Descriptors Length = 0Ch
40 Protocol Identifier Code Set = 1
41 PIV=1 RSVD Association = 1 Identifier Type = 3
42 Reserved = 0
43 Identifier Length = 8
44-51
(MSB)
Secondary Target Port Identifier (World Wide ID)
(LSB)
