CHAPTER 11
Echo Software
76 StudioPix™ Pixelation Luminaire User Manual
If you click on the Status Bar, a
window will open to show the
ongoing status of the discovery
process and note any errors.
When the launch is complete, all SHOWPIX, StudioPix
and discovered devices will be listed in the under
Devices in the navigation pane along with their current
DMX Start Address.
The Echo User Interface
Echo software uses a typical Windows explorer structure for organizing Device information and
Content.
• The top level of the navigation pane contains Devices, User Content, and Stock Content.
• At each navigation level you can display the contents as a list or a preview by selecting the
tab in the pane.
• You can click on a Column Heading to sort the content displayed by Name or Address.
Navigation pane Contents pane
Column Heading View Tabs
Folder/File List DMX Address
