CHAPTER 3
The Menu System
16 StudioPix™ Pixelation Luminaire User Manual
StudioPix Menu Map
Level 1 Level 2 Level 3 Description
ADDR Cxxx Change the existing DMX start channel
SET
FACT
ON Sets factory defaults on
OFF Sets factory defaults off
DSPL
ON Sets the LED display on
OFF Sets the LED display off
P/IN
ON Sets pan invert on
OFF Sets pan invert off
T/IN
ON Sets tilt invert on
OFF Sets tilt invert off
SWAP
ON Sets pan/tilt swap on
OFF Sets pan/tilt swap off
DLOS
LONG Keeps LED state until shutdown after DMX data is lost
SHRT Turns LEDs off one second after DMX data is lost
MODE PROT
STD Selects Standard protocol
ENH Selects Enhanced protocol
PIX Selects Pixel Mapping protocol
RGB Selects RGB protocol
TEST
HOME HOLD Homes the fixture
SELF
PAN Moves the head through the full pan range
TILT Moves the head through the full tilt range
RED Turns all LEDs red
GRN Turns all LEDs green
BLUE Turns all LEDs blue
PIX Turns each individual LED on
INFO
VER #### Displays the
TEMP
BASE Displays electronic housing internal temperature
HEAD Displays the head internal temperature
F/HR #### Displays current number of fixture hours
DMX 1-512 Displays the DMX data for the selected DMX channel
UNIQ Displays the fixture’s unique ID number
