CHAPTER 6
Color Control
StudioPix™ Pixelation Luminaire User Manual 39
Random Color
Color Function parameter DMX value = 18
Red Parameter: Controls the cycle speed from 0 = slow to maximum speed at a DMX value =
255 (100%).
Green Parameter: Not used
Blue Parameter: Not Used
Replace Background Color
Color Function parameter DMX value = 22
Selects the background color to be viewed through transparent components of the image.
Red Parameter: Increases the red color component from 0 = no adjustment to 65,535 (100%)
= maximum red saturation.
Green Parameter: Increases green color component from 0 = no adjustment to
65,535 (100%) = maximum green saturation.
Blue Parameter: Increases blue color component from 0 = no adjustment to 65,535
(100%) = maximum blue saturation.
RGB Add non-black pixels
Color Function parameter DMX value = 4
This option adds color to all pixels except black using the RGB color model.
Red Parameter: Increases the red color component from 0 = no adjustment to 65,535 (100%)
= maximum red saturation.
Green Parameter: Increases green color component from 0 = no adjustment to
65,535 (100%) = maximum green saturation.
Blue Parameter: Increases blue color component from 0 = no adjustment to 65,535
(100%) = maximum blue saturation.
RGB Add, All Pixels
Color Function parameter DMX value = 0
This option adds color to all pixels including black using the RGB color model.
Red Parameter: Increases the red color component from 0 = no adjustment to 65,535 (100%)
= maximum red saturation.
Green Parameter: Increases green color component from 0 = no adjustment to
65,535 (100%) = maximum green saturation.
Blue Parameter: Increases blue color component from 0 = no adjustment to 65,535
(100%) = maximum blue saturation.
