CHAPTER 6
Color Control
StudioPix™ Pixelation Luminaire User Manual 41
RGB Swap to BGR
Color Function parameter DMX value = 7
This option allows you to swap colors. All red values become green and all blue values become
red. Green values are unaffected.
Red Parameter: Transitions red color component to blue from 0 = no color change to
65,535 (100%) = green
Green Parameter: No change to green color component
Blue Parameter: Transitions blue color component to green from 0 = no color change to
65,535 (100%) = red
RGB Swap to BRG
Color Function parameter DMX value = 6
This option allows you to swap colors. All red values become blue, all green values become red
and all blue values become green.
Red Parameter: Transitions red color component to blue from 0 = no color change to
65,535 (100%) = blue
Green Parameter: Transitions green color component to red from 0 = no color change to
65,535 (100%) = red
Blue Parameter: Transitions blue color component to green from 0 = no color change to
65,535 (100%) = green
RGB Swap to GBR
Color Function parameter DMX value = 5
This option allows you to swap colors. All red values become green, all green values become
blue and all blue values become red.
Red Parameter: Transitions red color component to green from 0 = no color change to
65,535 (100%) = green
Green Parameter: Transitions green color component to blue from 0 = no color change to
65,535 (100%) = blue
Blue Parameter: Transitions blue color component to red from 0 = no color change to
65,535 (100%) = red
