CHAPTER 9
Image Graphics Control
58 StudioPix™ Pixelation Luminaire User Manual
The following table describes the stock content folders available on SHOWPIX and StudioPix
fixtures.
Media Folder Descriptions
Media File
The Media File parameter lets you identify a media file. You can supplement the large library of
stock content with custom files. This parameter selects media files from within the folder defined
by the Media Folder parameter.
For a reference of files available as stock content with your SHOWPIX or StudioPix fixture,
go to the Stock Content Guide link on the SHOWPIX or StudioPix support page on
http://www.highend.com/support/LED/ . You can also preview images of media files in
the Echo application.
Default DMX Value: 0 = No file selected
DMX
Value
Media Folder Name Content Description
1 Lenses
Optimized static patterns that produce unique lens looks for wash light
applications
2 Backgrounds
Animated Images with no black pixels to be used behind a transparent icon,
lens, or moving image
3 Chasing Changing animations that repeat patterns
4 Marquee Frame by frame LED animations
5 Atmospherics Natural, organic, and fluid movements and animations
6 Elegant Slow graceful flowing
7 Shimmer Sparkling and elegant
8 Fiery Flames, explosions, etc
9 Spinning Rotating and turning animations
10 Icons Recognizable images such as alpha numerics, symbols and emblems
11 Realistic Representations of real life imagery
12 Flashing Strobing and flashing images
41-250 Open Available for user content
255 Pixel Mapping Input Select the pixel mapping option when using Enhanced DMX protocol mode
