CHAPTER 3
The Menu System
StudioPix™ Pixelation Luminaire User Manual 17
StudioPix Menu Options
The sections below explain how to access the fixture options shown in the fixture’s menu map.
This manual uses the following conventions in the descriptions for menus and menu navigation
buttons:
Address Menu (AddR)
The DMX start channel identifies each fixture on a DMX link. You must assign a DMX start
channel to each fixture on the link.
The Address menu allows you to change the DMX start channel that is currently assigned to the
fixture. Be sure you do not overlap fixture channel ranges when changing the DMX start
channel. For more information, see Determining a DMX Start Channel on page 24.
To change the DMX start channel:
1. Press and hold
2. Select a new DMX start channel. The LED display flashes when a new start channel is
selected.
3. Press to accept the new DMX start channel. The LED display stops flashing when a
new option is entered. If you do not press , the new option you selected is not
stored.
Set Menu (SET)
Setting Factory Defaults (FACT)
When you set this menu item on, all factory options return to their default settings. StudioPix
fixtures are shipped from the factory with the following default option settings:
The factory default menu option displays On if all the factory options are at the factory default
settings. If any of the items listed above are not at the factory default setting, the display reads
OFF. Selecting the OFF option will have no effect. To restore the factory default setting:
1. Press and hold
2. Scroll to the SET menu. Press to select.
3. Scroll to the FACT menu (this will be the first menu displayed). Press .
4. Scroll to ON to restore the factory option defaults.
5. Press to store.
Example Meaning
Press the appropriate LED display navigation button on the fixture. For example, the
button on the LED display panel.Menu OptionItalics are used to indicate the appropriate menu selection you should choose from the
on-board menu system. For example, the AddR menu option.pan/tilt swap = off
tilt invert = offpan invert = off
LED display = on and brightLED off with DMX data loss = short
Press the appropriate LED display navigation button on the fixture. For example, the
button on the LED display panel.
Menu Option
Italics are used to indicate the appropriate menu selection you should choose from the
on-board menu system. For example, the AddR menu option.
pan/tilt swap = off
tilt invert = off pan invert = off
LED display = on and bright LED off with DMX data loss = short
