CHAPTER 4
DMX Programming Basics and Quick Start
26
StudioPix™ Pixelation Luminaire User Manual
RGB Reduced Protocol
This protocol choice lets you utilize SHOWPIX and StudioPix fixtures as powerful wide angle
washlights by providing control of motion and color mixing only.
Note: Reduced protocol provides 8-bit color control instead of the 16-bit
color mixing used in the Standard Protocol
RGB Reduced Protocol Table
for SHOWPIX and StudioPix
Chan #
Description
1
Pan
2
3
Tilt
4
5
Mspeed
6
Macro
7
Control Function
8
Strobe
9
Dim
10
Red
11
Green
12
Blue
