CHAPTER 3
The Menu System
StudioPix™ Pixelation Luminaire User Manual 19
Swapping Pan and Tilt (SWAP)
This menu option swaps the pan motor and tilt motor operation to allow fixtures hung
perpendicular to each other to respond to pan and tilt movement commands in the same
direction. To swap pan and tilt motion:
1. Press and hold
2. Scroll to the SET menu. Press to select.
3. Scroll to the SWAP menu. Press to select.
4. Scroll to ON to swap the fixture’s pan and tilt motion, or OFF to return the fixture’s pan and
tilt motion to normal orientation.
5. Press to store.
Data Loss (DLOS)
Use this menu item to determine how the fixture will react in the event of DMX data loss by
turning off the LED’s upon Data Loss or keeping the LEDs on until shut down.
To select a data loss option:
1. Press and hold
2. Scroll to the SET menu. Press to select.
3. Scroll to the dLOS menu. Press to select.
4. Scroll to LONG to turn the LEDs off only when the fixture is shut down, or SHRT to turn off
the LEDs one second after data loss.
5. Press to store.
Mode Menu (MODE)
Setting Protocol Option (PROT)
Use this menu item to change the current protocol option:
1. Press and hold
2. Scroll to the MODE menu. Press to select.
3. Scroll to the PROT menu (this will be the first option displayed). Press .
4. Scroll to STD for Standard protocol, EHN for Enhanced protocol, PIX for Pixel Mapping
protocol or RGB for wash light functionality.
5. Press to store.
