CHAPTER 8
Global Control: Transitions
StudioPix™ Pixelation Luminaire User Manual 53
7 Diamond In A diamond pattern opens Out from the center or In
from the edge in the first Image layer to reveal the
second Image layer.
Reveal
8 Diamond Out
9 Box In A box pattern opens Out from the center or In from the
edge in the first Image layer to reveal the second
Image layer.
Reveal
10 Box Out
11 Split Horizontal In Splits the screen horizontally and opens Out from the
center or In from the edge in the first Image layer to
reveal the second Image layer.
Reveal
12 Split Horizontal Out
13 Split Vertical In Splits the screen vertically and opens Out from the
center or In from the edge in the first Image layer to
reveal the second Image layer.
Reveal
14 Split Vertical Out
15 Blinds Horizontal
Simulates Horizontal or Vertical venetian blinds
opening in the first Image to reveal the second Image.
Reveal
16 Blinds Vertical
17 Checkerboard Horizontal A checkerboard pattern opens horizontally or vertically
in the first Image layer to reveal the second Image
layer.
Reveal
18 Checkerboard Vertical
19 Comb Horizontal A pattern simulating the teeth of a comb moving
together Horizontally or Vertically in the first Image to
reveal the second Image.
Reveal
20 Comb Vertical
21 Random Bars Horizontal A random bar pattern moving Horizontally or Vertically
in the first Image to reveal the second Image.
Reveal
22 Random Bars Vertical
23 Strips Left Up
A diagonal stripe pattern opens in the first image layer
from different positions to reveal the second image
layer.
Reveal
24 Strips Right Up
25 Strips Left Down
26 Strips Right Down
27 Wedge from Left
A wedge of the circular array opens toward the center
in different directions to reveal the second layer
Reveal
28 Wedge from Right
29 Wedge from Up
30 Wedge from Down
31-38
Wheel 1 spoke, clockwise
rotation
A wheel with different spoke and rotation options opens
on the first image layer to reveal the second image
layer.
Reveal
32
Wheel 2 spokes, clockwise
rotation
33
Wheel 3 spokes, clockwise
rotation
34
Wheel 6 spokes, clockwise
rotation
35
Wheel 1 spoke,
counterclockwise rotation
36
Wheel 2 spokes,
counterclockwise rotation
37
Wheel 3 spokes,
counterclockwise rotation
38
Wheel 6 spokes,
counterclockwise rotation
DMX
Value
Transition
Pattern
Description
Transition
Type
