CHAPTER 6
Color Control
36 StudioPix™ Pixelation Luminaire User Manual
Color Function Parameter
In Standard and Extended protocol, the Color Function parameter is available at both the
image level and the global level. This gives you the ability to apply a color effect to one or both
image layers and also to the composite image.
NOTE: Choosing a Color Function may change the functionality of the Red,
Green and Blue channels.
The following section provides a more detailed description of Color Function parameter options
in alphabetical order.
Color Function Parameter Adjustments
DMX
Value
Option Description
Red
Parameter
Green
Parameter
Blue
Parameter
0 RGB Add. Standard RGB add to all Pixels Red Green Blue
1 CMY. Simulates CMY by subtracting RGB Cyan Magenta Yellow
2 Black and White.
3 Black and White Inverted.
4 RGB Add non-black pixels. Red Green Blue
5 RGB Swap to GBR. redefines component color Red to Green Green to Blue Blue to Red
6 RGB Swap to BRG. redefines component color Red to Blue Green to Red Blue to Green
7 RGB Swap to BGR. redefines component color Red to Blue Green Blue to Red
8 RGB Swap to RBG. redefines component color Red Green to Blue Blue to Green
9 RGB Swap to GRB. redefines component color Red to Green Green to Red Blue
10
RGB Invert. converts red to inverted red, green to
inverted green, blue to inverted blue Red
to Cyan
Green to
Magenta Blue to
Yellow
11
RGB Invert & Swap to GBR. converts red to inverted
green, green to inverted blue, blue to inverted red
Red to
Magenta
Green to
Yellow
Blue to
Cyan
12
RGB Invert & Swap to BRG. Red to inverted blue,
green to inverted red, blue to inverted green Red to
Yellow
Green to
Cyan
Blue to
Magenta
13 Solarize 1 If color value < threshold value, invert color Red Green Blue
14 Solarize 2 If color value > threshold, invert color. Red Green Blue
15 Solarize 3 If color value < threshold, set color to 0 Red Green Blue
16 Solarize 4 If color value > threshold, set color to 0 Red Green Blue
17 Color Cycle DMX value controls cycle speed. Red Green Blue
18 Random Color Sets Rate Not Used Not Used
19 Scale multiplies the color values Red Green Blue
20
Compress to Maximum reduces the color value
range from minimum to 65,635 Sets Red
Minimum Sets Green
Minimum
Sets Blue
Minimum
21 Add color to black adds RGB to black pixels Red Green Blue
22 Replace Background Color Red Green Blue
23 Rainbow Color Cycle
Controls
cycle speed
Controls color
offset
Not Used
