CHAPTER 3
The Menu System
20 StudioPix™ Pixelation Luminaire User Manual
Test Menu (TEST)
The Test menu allows you to manually home the fixture and perform fixture self tests to
determine the origin of mechanical problems.
Homing the Fixture (HOME)
This menu item allows you to manually home the fixture. To remotely home the fixture using a
DMX console, see Control Function Options on page 34. To manually home the fixture:
1. Press and hold
2. Scroll to the TEST menu. Press to select.
3. Scroll to the HOME option (this will be the first option displayed).
4. Press to store.
Performing Self Tests (SELF)
The following self tests are available:
To start a self test process:
1. Press and hold
2. Scroll to the TEST menu. Press to select.
3. Scroll to the SELF menu. Press to select.
4. Scroll to the desired option (listed above).
5. Press to start the test. The fixture will perform the selected self test.
6. Press
Construct Self-Test Description
ALL Performs all of the self tests listed below
PAN Moves the head through the full pan range
TILT Moves the head through the full tilt range
RED Turns all LEDs red
GRN Turns all LEDs green
BLUE Turns all LEDs blue
PIX Turns each individual LED on
