HP 2000CP 2500CP User Manual
Page 303

8-82
Removal and Installation
HP DesignJet CP Series Printers
Installation
1. Install the three T-20 screws (item 6) securing the left hand roll feed
assembly to the left hand side chassis.
2. Install the three T-20 screws (item 7) securing the right hand roll feed
assembly to the right hand side chassis.
3. Install the roll cover (item 4) into the correct position in the roll feed
assemblies.
4. Move the adjustment bracket as far left as it can go to secure the roll
cover to the left hand chassis, then tighten the nuts (item 5) on the
adjustment bracket.
5. Install the two roll cover springs (item 3) onto the roll cover with two
T-10 screws (item 2).
6. Install the spindle assembly (item 1) by pushing it into the retaining
clips in the roll feed assembly.
7. Install the following:
1. Service Station Assembly
' page 8-26.
2. Right Hand Cover
' page 8-21.
3. Left Hand Cover
' page 8-18.
4. Window and Top Cover
' page 8-15.
8. Connect the power cord.
