8-58

Removal and Installation

HP DesignJet CP Series Printers

Bail Assembly and Star Wheel Assemblies

Refer to figure 20

' page 8-59

Removal

1. Open the window.

2. Manually move the carriage assembly to the left side of the printer.

3. Lifting up the bail assembly (item 1), push both the plastic arms at the

end of the bail assembly together. This will release it from holes in the
left and right hand side chassis.

4. Remove the right side of the bail arm first and then the left.

Note: If the mark encoder which is glued to the drive roller obstructs
the removal of the bail assembly, press
Form Feed and Cut this will
move the drive roller around.

5. Remove the star wheel assemblies (item 2) by pushing together the

retaining clips and pulling them off

Installation

1. Install the star wheel assemblies (item 2) by pushing the retaining clips

into the bail assembly (item 1).

2. Install the bail assembly by installing the left side first, then install the

bail assembly into holes in the left and right hand side chassis.

3. Close the window.

4. Perform D11 Bail Service Test

' page 4-25
