Removal and Installation

8-3

HP DesignJet CP Series Printers

Starguard Assembly

8Ć60

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Bail Stepper Motor

8Ć62

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Refill Interconnect PCA

8Ć64

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

XĆAxis Assembly

8Ć66

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Overdrive Assembly and Drive Roller (Only 2500CP/2000CP)

8Ć69

. . . . .

Overdrive Assembly and Drive Roller (Only 3500CP/3000CP)

8Ć72

. . . . .

Entry Platen

8Ć78

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Roll Cover and Roll Feed Assemblies

8Ć81

. . . . . . . . . . . . . . . . . . . . . . . . . .

Pincharm Assemblies, Pincharm Shaft and Pincharm Sensor

8Ć84

. . . . . . .

Interconnect Cables

8Ć87

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Media Button (Only DesignJets 3500CP and 3000CP)

8Ć90

. . . . . . . . . . . .

Introduction

This chapter is a step by step guide to the removal and installation of the
key components in the printer. You may find it useful to tick off the steps as
they are performed. Use the illustration at the end of each procedure to
identify the parts referred to in the text.

The procedures appear in order of removal. So the whole machine can be
stripped down by starting at the beginning of this chapter and working
through the subsequent procedures.

Before using this chapter to remove and install a new component,
always make sure that you have performed the relevant service test
from Chapter 4. If the test passes you will not need to replace the
component.
