242 Parts and diagrams
EN
Alphabetical parts list
Table 38. Alphabetical parts list
Part name
Part number
Figure #
Reference
Arm, plate, left
RB1-7185-000CN
96
16
Arm, plate, right
RB1-7186-000CN
96
17
Bottom plate
RB2-3342-000CN
95
2
Bushing
RB1-7184-000CN
96
5
Bushing (2)
RB1-7246-000CN
94
2
Bushing (2)
RB1-7288-020CN
93
2
Cable guide
RB1-7130-020CN
92
6
Cable guide
RB2-3409-000CN
89
19
Cable guide holder, formatter
RB2-3366-000CN
92
8
Cable guide, control panel
WT2-5178-000CN
92
14
Cable guide, formatter
RB2-3350-000CN
92
3
Cable guide, frame
WT2-5300-000CN
92
15
Cable tube
RB2-3351-000CN
89
13
Cable, CIS grounding
RG5-4238-000CN
89
22
Cable, contact image sensor (J1004 to
J903)
RG5-4233-000CN
89
21
Cable, door switch
RG5-3662-000CN
95
9
Cable, formatter
RH2-5346-000CN
95
6
Cable, grounding, document scanner motor RG5-4237-000CN
92
20
Cable, laser
RG5-2035-000CN
95
5
Cable, LIU
C3948-60102
95
Cable, motor
RG5-2033-000CN
95
11
Cable, paper pickup
RG5-2029-000CN
95
8
Cable, scanner
RG5-3661-000CN
95
12
Cable, thermistor
RG5-2032-000CN
95
10
Cap
RB1-7234-000CN
92
7
Cap
RB2-3345-000CN
92
1
Clamp, cable
WT2-0367-000CN
95
14
Clamp, cable
WT2-5178-000CN
95
15
