Installing the stand – Dell 23.8" OptiPlex 7410 All-in-One Desktop Computer (Gray) User Manual

Page 39

Text mode
Original mode

Steps

1. Place the display-assembly base on a clean and flat surface.
2. Press and hold down on the tab that secures the stand to the display-assembly base.
3. Slide and lift the stand off the display-assembly base.

Installing the stand

Prerequisites

If you are replacing a component, remove the existing component before performing the installation process.

About this task

NOTE:

Depending on the stand you are installing onto your computer, refer to the corresponding image shown in the

procedure.

The following image(s) indicate the location of the stand and provides a visual representation of the installation procedure.

Removing and installing Customer Replaceable Units (CRUs)
