Data Projector

VPL-GTZ380

Connecting to a Workstation

You can display a “4096 × 2160” or “3840 × 2160” high resolution image by connecting the projector and workstation with
one or two DisplayPort cables (not supplied). When making the V Split display connection with two DisplayPort cables,
connect the DisplayPort 1 input and DisplayPort 2 input on the projector to the DisplayPort 1 output and DisplayPort 2
output on the workstation respectively.

: Signal flow

Note

Use a “HBR3 (High Bit Rate 3)” DisplayPort cable. If using a cable other than a HBR3 (High Bit Rate 3) DisplayPort cable, 4K
images may not be displayed correctly.

If an image from a workstation connected with a DisplayPort cable is not displayed, check the settings of the connected
workstation and graphic board.
