Sony BRAVIA XR A95K 55" 4K HDR Smart QD-OLED TV - Manual (Page 35)

To return the lens position
Press the RESET button on the remote control while the Lens shift adjustment window is displayed. The lens returns to
the center (factory default position). (The zoom and focus settings are not changed.)
Range of movement on the projected image
You can move the projected image only within the octagon area shown in the figure below. The movable range depends
on the lens or the aspect ratio of the projected image.
A: One screen width
: Image position when moving the image fully to the left
: Image position when moving the image fully to the right
To adjust the vertical position
Press the / (Up/Down) button to move the projected image vertically from the center of the lens.
Side view
A: One screen width
: Image position when moving the image fully upward
: Image position when moving the image fully downward
35
