Help Guide

Linear PCM Recorder

PCM-A10

Display window while recording is in progress or on standby

The following describes the display window while recording is in progress or on standby.

A: During recording with manual volume adjustment
B: During recording with the Auto Gain Ctrl function

Note

The above screen is provided for explanatory purposes. It may look different from what you actually see on your linear PCM
recorder.

Recording status indicator
Indicates the current recording status of your linear PCM recorder.

: recording

: paused (The indicator flashes.)
: stopped

1.

Peak level meters
Indicate the current and optimum recording volume levels of input sound for your reference.
If too loud sounds are detected during recording, [OVER] appears.

2.

Track mark number
Indicates the number of added track marks.

3.

Bluetooth indicator
Indicates that the Bluetooth function is turned on.

4.

Remaining recording time
Indicates the remaining time available for recording in hours, minutes, and seconds.
10 hours or more: no indication
10 minutes to 10 hours: indicated in hours and minutes
Less than 10 minuets: indicated in minutes and seconds

5.

Sleep timer indicator
Indicates that the sleep timer is active.

6.

REC Mode indicator
Indicates the recording mode that is currently selected.
LPCM 96/24, LPCM 48/24, LPCM 48/16, LPCM 44/24, LPCM 44/16: LPCM file
MP3 320k, MP3 192k, MP3 128k, MP3 48k: MP3 file

7.
