Input impedance: approx. 3.9 kΩ
Rated input level: approx. 2.5 mV
Minimum input level: approx. 1 mV
Audio IN
Input impedance: approx. 4.7 kΩ
Rated input level: approx. 2 V
Minimum input level: approx. 18 mV
Output jack (stereo mini-
jack)
Headphones
Recommended load impedance: 16 to 32 Ω
USB connector
Type-A, High-Speed USB compatible
Card slot
microSD memory card slot
Playback speed control
(DPC)
1.00 times - 0.25 times: FLAC files with the sampling frequency at 88.2 kHz or
higher
2.00 times - 0.25 times: LPCM files with the sampling frequency at 88.2 kHz or
higher, FLAC files with the sampling frequency at 88.2 kHz or lower
3.00 times - 0.25 times: other than the above
Power output
200 mW
Power requirements
Built-in rechargeable lithium-ion battery: 3.7 V DC
Ambient conditions
Operating temperature: 5 °C - 35 °C (41 °F - 95 °F)
Operating humidity: 25 % - 75 %
Storage temperature: -10 °C - +45 °C (14 °F - 113 °F)
Storage humidity: 25 % - 75 %
Dimensions (w/h/d) (not incl.
projecting parts and
controls)
Approx. 39.2 mm × 109.5 mm × 16.0 mm (1.55 inches × 4.32 inches × 0.63 inches)
(Width/Height/Depth)
Mass
Approx. 82 g (2.90 oz)
Supplied accessories
See Operating Instructions supplied with your linear PCM recorder.
Some of the built-in memory is used for file management.
*1
Applies when the built-in memory is formatted by the linear PCM recorder.
*2
Not all encoders are supported.
*3
Playback of the MP3 files recorded by the linear PCM recorder is also supported.
*4
WMA Ver.9 is compatible, however, MBR (Multi Bit Rate), Lossless, Professional, and Voice are not supported.
*5
Copyright-protected files are not available for playback.
*6
176.4 kHz and 192 kHz are down-sampled to 88.2 kHz and 96 kHz, respectively, for playback.
*7
Varies depending on the communication conditions.
*8
A Bluetooth profile is a specification that standardizes features of individual characteristics of the Bluetooth device.
*9
Audio compression conversion method
*10
187
