62
Menu List
13: Ctl/Exp
Menu item Value (Bold: default) Explanation
Ctl/Exp 1 [Enter] These settings for the footswitch or expression pedal connected to the CTL/EXP 1 jack.
Ctl/Exp 2 [Enter] These settings for the footswitch or expression pedal connected to the CTL/EXP 2 jack.
Ctl/Exp 1, Ctl/Exp 2
Menu item Value
(Bold: default)
Explanation
Ctl/Exp Type
Settings for the devices (footswitch or expression pedal) connected to the CTL/EXP 1, 2 jacks.
Off Disables the CTL/EXP jack.
Ctl A & Ctl B Choose this if a footswitch is connected.
Exp Choose this if an expression pedal is connected.
Ctl A Assign (*4)
Ctl B Assign (*4)
Specifies the functions that are assigned to CTL A and CTL B of the footswitch.
N/A No function is assigned.
INPUT SELECT Switches the final input video.
REC Start Starts recording.
REC Stop Stops recording.
Mark IN Sets the IN point.
Mark OUT Sets the OUT point.
MAKE CLIP Creates a clip whose OUT point is the moment at which you depress the footswitch.
Select Prev Clip Selects the clip just before the currently selected clip.
Select Next Clip Selects the next clip after the currently selected clip.
AUTO PLAY CLIP Plays back the clip.
AUTO PLAY PLAYLIST Plays back the playlist.
Add BOOKMARK Adds a bookmark.
Jump to Prev BOOKMARK Jumps to the previous bookmark.
Jump to Next BOOKMARK Jumps to the next bookmark.
Jump to Top Jumps to the beginning of the recorded video.
Jump to End Jumps to the end of the recorded video.
Exp Assign (*5)
Specifies the function that is assigned to the expression pedal.
N/A No function is assigned.
Speed Control Adjusts the playback speed.
LIVE IN Ë REPLAY
Switches between the live in video (when the pedal is pushed up with your toes) and
the replay video (when the pedal is pushed down with your heel).
REPLAY Ë LIVE IN
Switches between the replay video (when the pedal is pushed up with your toes) and
the live in video (when the pedal is pushed down with your heel).
AUDIO OUTPUT LEVEL Adjusts the output level of the main bus.
Exp Calibration (*5) [Enter]
Calibrate (adjust) the expression pedal.
The first time you use the expression pedal, be sure to execute calibration so that the
pedal will operate optimally.
In some cases, the expression pedal might no longer be operating optimally because
of the passage of time or the conditions of use. In such cases you should also execute
expression pedal calibration.
(*4) This is valid when Ctl/Exp Type is set to “Ctl A & Ctl B.”
(*5) This is valid when Ctl/Exp Type is set to “Exp.”
