Appendix C: Technical Specifications
Computer Video Port Pin Assignments
The Computer port is a female video RGB, 15-pin micro-D-style
connector. Here are its pin assignments:
Pin no.
Computer port
1
Red video
2
Green video
3
Blue video
4
Monitor (ID bit 2)
5
GND
6
Red video GND
7
Green video GND
8
Blue video GND
9
+5 V
10
Synchronous GND
11
Monitor (ID bit 0)
12
SDA
13
Horizontal sync
14
Vertical sync
15
Reserved
