Troubleshooting
258 Xerox ® WorkCentre ® 7800/7800i Series Color Multifunction Printer
User Guide
Clearing Jams in the Integrated Finisher
1. Locate the Integrated Finisher mounted beneath the scanner and control panel.
2. Open the top cover of the finisher (1).
3. Turn the green knob in the direction shown to remove the paper (2).
4. To remove the paper, pull it in the direction shown.
Note: If the paper is torn, remove all torn pieces from the printer.
5. Close the top cover of the Integrated Finisher.
Clearing Jams in the Office Finisher LX
Clearing Jams Under the Finisher Top Cover
1. Pull up the lever on the top cover.
2. Open the top cover by rotating it to the left.
