54 Replacing the Photo Cartridge
L Proof Sign-off:
H. Yamasaki CRE Nakano
M. Otsuka
editor name R4CF95P
SHORT.bk
Rev. D
INK.FM A5 size
2/15/05
❏ Be sure to always install a photo
cartridge into the printer immediately
following the removal of the current
photo cartridge. If a photo cartridge is
not installed promptly, the print head
may dry out, rendering it unable to
print.
9. Place the cartridge properly into the cartridge
holder, then push it in until you feel resistance
and hear the cartridge faintly click into place.
Note:
After installing the cartridge, make sure the sides of the
cartridge are even. If either side of the cartridge sticks
out, push the side of the cartridge until it clicks.
