Connecting and Disconnecting the
Bluetooth Photo Print Adapter
Connecting
1. Insert the Adapter connector into the EXT/IF port
as shown below.
c Caution:
Do not connect this product while the
printer is operating. Doing so may cause
the printer to malfunction.
2. The Adapter’s light comes on for one second. If
the LED does not turn on, disconnect the Adapter
from the printer, then reconnect it.
Disconnecting
Remove the Adapter’s connector from the EXT/IF
port as shown below.
